Simplicity and compatibility

With the ACH480 HVAC drives, you optimize your HVAC systems effortlessly. These compact drives are designed for easy cabinet installation, perfect for HVAC OEMs and panel builders.

The ACH480 drives offer precise control over fans, pumps, compressors, and complex HVAC equipment like air-handling units. Built-in features streamline installation, while the HVAC-specific control panel simplifies startup, commissioning, and operation.

product-image-9IBA242011-ach480-04-r1-left-bluetooth-panel-1_1x1-L

Download ACH480 drives catalogue (PDF)

Technical data

22 kW

wide power range all the way from 0.75 kW

480 V

wide voltage range all the way from 200 V

IP20

enclosure classes

Key benefits

The ACH480 drives offer seamless integration with a wide range of motors and communication protocols, combining compact design with advanced HVAC-specific features for reliable and efficient operation in space-constrained installations.

Shared resources
Share components like chokes and control panels across drives, reducing costs and simplifying setup.
Enhanced protection
The UL Type 1 kit adds protection, enabling compliant wall mounting worldwide.
Space saving
Uniform drive dimensions save valuable cabinet space, keeping installations compact and organized.
Flexible installation
Uniform enclosure size, DIN-rail and screw mounting, and zero side clearance offer versatile installation options.
Reliable performance
Coated boards, fault protection, and operation at up to 50 °C ensure dependable performance.
Instant availability
HVACR drives are readily available from ABB partners and distributors for quick delivery.
